GTD Car Specs
Through its partnership with Wayne Taylor Racing (WTR), the No. 93 Harrison Contracting Company Acura NSX GT3 Evo22 will be operated by Racers Edge Motorsports in the four most prestigious endurance racing events in North America—the Rolex 24 at DAYTONA, Mobil 1 Twelve Hours of Sebring, Sahlen’s Six Hours of the Glen and MOTUL Petit Le Mans. Ashton Harrison, Kyle Marcelli and Daniel Formal will pilot the GTD class entry, with decorated sports car driver Ryan Briscoe joining the lineup at Daytona.
Car Specs
NO. 93 HARRISON CONTRACTING COMPANY ACURA NSX GT3 EVO22: TECHNICAL SPECIFICATIONS
TRANSMISSION
Gearbox- 6 speed sequential XTRAC semi-automatic with paddle shift
Clutch - 3 discs SACHS sintered or carbon
Clutch Operation - electrically assisted
Driveline Pankl - double tripod
ENGINE
Cylinders| Capacity - DOHC V6-75° 3501cc twin turbocharged
Layout - longitudinal mid-mounted
Lubrification - dry sump system
ECU Pectel MQ12 Exhanust - Twin pipe with CAT converter
SUSPENSION
Front -double wishbone
Rear --multilink
Shock Absorber - SACHS 5 way adjustable
Sway Bar - FR/RR with adjustable blade
BRAKES
Front BREMBO - 6 pistons calipers - 390x34mm discs
Rear BREMBO - 4 pistons calipers - 355x32mm discs
ABS - BOSCH M5
WHEELS
Front Tires - 30/68 -18 (Michelin), 12x18" O.Z. Racing forged aluminum rims
Rear Tires - 31/71 -18 (Michelin), 13x18" O.Z. Racing forged aluminum rims
ELECTRONICS
Display - BOSCH DDU10
Data Logger - BOSCH C60
Power Box - BOSCH PBX90
DIMENSIONS AND WEIGHT
Wheelbase - 2630mm
Overall Length - 4509mm
Overall Width - 2046mm
Front Track - 1715mm
Rear Track - 1687mm
Weight - 1260kg
INTERNAL EQUIPMENT
Seat - SPARCO 8862/2009 floor mounted
Steering Wheel - multifunction JAS/OMP design
Source: https://jasmotorsport.com/racing-cars/honda-nsx-gt3-evo
